Carpet Cleaning Extractor
Carpet Cleaning Extractor
As the key machine for carpet cleaning function, contractor combine most of the functions into itself .
Features :
| Solution tank | 45L |
| Recovery tank | 38L |
| Optional colors | optional according to the required from customers |
| Working pressure | 0 - 500PSI - 1200PSI (Optional according to the required from customers ) : PUMP TEC |
| In-line Heaters | 1500W - 2000W (Optional as request ) |
| Vacumm motors | 2 sets 1400W -3-stage AMETEK vacumm motor |
| Spare parts | 2 x 10 inch wheels for easily move Plastic basket for chemical bottle loading Heating & recovery fresh water re-circuling system |
| Waste water | Water recovery rate : more than 90% (the most powerful in the industry) |
| Packing | Packing size : 450mm x 550mm x 800mm with 55kgs - 60kgs |
| Warranty | 2 years for whole machine . 3-5 years for motor and pressurised motore head AR & TM recovery tank auto pump-out functions ( Optional ) |
ATTN:
1. In Solution tank, we have Water-off alarming system : When the water spray out less than 5L , the alarming system will work to inform you to input the water. And this system will cut off the spray function to protect the spray pump .
2. In Recovery tank , we have self-cut system, when the recovery tank is full with the recovery water, this system will work to self-cut the vacuum function to stop vacuum.
3. The the base tank, we have heating-out fans to keep the working system cold and healthy.
This is our special design .
Carpet Cleaning Extractor
Powerful extractor is the key important machine for uphostery carpet cleaning technology in the industry , GRACIA design our patent extractor as the industry level to meet the different requirements from our customers.
Our slogan is " details make perfect " .
The best selling model is : E45/38 in US / EU / Middle East / Australia etc.
Color optional as your request in target market .
OEM service is acceptable .
Packing carton : 1100mm x 600mm x 800mm
Weight : 50-60 kgs
Body | • Roto-molded polyethylene housing |
Solution Tank | • 37.9 L capacity |
Vacuum Tank | • 37.9 L capacity |
Vacuums | Dual Vacuum Motors |
Pump | Pumptec Piston Pump |
Pump-out GPM | • 3.3 |
Automation | • Auto-fill for solution tank |
Cords | • Dual 15.2 m twist-lock 12/3 |
Amp Draw | • Cord 1: 20 amps |
Machine Weight | • 61.7 kg |
Machine Dimensions | • 72.4 cm x 47 cm x 95.3 cm |
Shipping Weight | • 68 kg |
Shipping Dimensions | • 74.3 cm x 47 cm x 125.7 cm |
